Forest Dresden Traversing: a German-made traversing rod with solid brass fittings
Dresden traversing rod by Forest, with 2026 retail prices, sizes, finishes and specifications.
What is the Forest Dresden Traversing?
The Forest Dresden Traversing rod is a 1 1/8 inch German-made aluminum rail with finials and brackets in solid brass, drawn by hand or baton, rated for 4 lb of drapery per foot. It curves to an 8 inch radius. A 6 ft Forest Dresden traversing rod (single) costs $1,368.71; a 12 ft one costs $2,328.53. A 6 ft Forest Dresden traversing rod (double) costs $2,736.84; a 12 ft one costs $4,654.86.
Dresden is Forest's most traditional traversing rod: the drapery runs on carriers inside the rail, so it opens and closes like a track, but the room sees a round rod and brass hardware. Nine finishes run from polished chrome and satin brass to bronze matte, plus beech, oak and walnut for the poles. Brackets step up with the length, from two up to 60 inches to five at 240 inches. Finials range from a plain end cap to the Pescara and Alassio designs listed below.
Forest Dresden traversing rod specifications
Forest's published figures for the US market (forestdh.com, the 2026 brochure and the 2026 catalog).
| Profile | 1 1/8 in German-made aluminum rail; finials and brackets in solid brass |
|---|---|
| Maximum fabric weight | 4 lb per foot, depending on the application |
| Mounting | Wall or ceiling |
| Operation | Hand or baton draw, one-way or center-open, pinch pleat or ripplefold |
| Bends and curves | Curves and reverse curves to an 8 in radius or a continuous curve (exact template required) |
| Brackets | 2 up to 60 in, 3 to 120 in, 4 to 180 in, 5 to 240 in |
| Finishes | 9: 22 Polished Chrome, 24 Satin Brass, 29 Satin Nickel, 48 Matte White, 59 Black, 70 Bronze Matte, and 222 Beech, 223 Oak, 224 Walnut (poles only) |
| Assembled set | Rail with its end cap finial and end stop, masters, carriers, brackets and a 36 in white fiberglass baton |
How much does a Forest Dresden traversing rod cost?
A 6 ft Forest Dresden traversing rod (single) costs $1,368.71; a 12 ft one costs $2,328.53.
A 6 ft Forest Dresden traversing rod (double) costs $2,736.84; a 12 ft one costs $4,654.86.
| Length | Single | Double |
|---|---|---|
| 3 ft | $1,048.77 | $2,097.50 |
| 4 ft | $1,048.77 | $2,097.50 |
| 5 ft | $1,208.74 | $2,417.17 |
| 6 ft | $1,368.71 | $2,736.84 |
| 8 ft | $1,688.65 | $3,376.18 |
| 10 ft | $2,008.59 | $4,015.52 |
| 12 ft | $2,328.53 | $4,654.86 |
| 14 ft | $2,648.47 | $5,294.20 |
| 16 ft | $2,968.41 | $5,933.54 |
| 20 ft | $3,608.29 | $7,212.22 |
| Option | First 4 feet | Each additional foot | Catalog page |
|---|---|---|---|
| Single | $1,048.77 | $159.97 | p. 47 |
| Double | $2,097.50 | $319.67 | p. 47 |
Forest prices an assembled system as one amount for the first 4 feet plus a fixed amount for each additional foot; the catalog prints no price for part of a foot, so a length between two whole feet is priced at the next whole foot, and anything up to 4 feet costs the 4-foot price. Longer runs are quoted at the measure.
Hardware only. Professional installation is quoted at the measure. Prices are 2026 retail, before tax, and may change.
Forest Dresden traversing rod parts and 2026 prices
27 parts and accessories with their 2026 retail prices, as printed in the Forest 2026 catalog. Parts sold by the box show the price each when bought by the full box, the box quantity, and the price each for a broken box. XX in a part number stands for the finish code; see the finishes below.
Show all 27 parts and prices
| Part number | Description | Finish or option | Price | Unit | Pack | Catalog |
|---|---|---|---|---|---|---|
| B124028-XX | End Cap Finial | $67.98 | each | p. 47 | ||
| B690-XX | Pescara Finial | $383.54 | each | p. 47 | ||
| B3362-XX | Alassio Finial | $388.37 | each | p. 47 | ||
| B124128-XX | Alea Finial | $96.44 | each | p. 47 | ||
| B610-XX | Napoli Finial | $482.35 | each | p. 47 | ||
| B3521-28-XX | Iscia Finial | $333.31 | each | p. 47 | ||
| B825-28-XX | 1 1/8" Dresden Rail 19' 7" | $53.53 | per ft | p. 48 | ||
| 2207-25 | 60% fullness, 2 5/8" OC | $2.38 | each | box of 500; broken box $2.84 each | p. 48 | |
| 2206-25 | 80% fullness, 2 3/8" OC | $1,190.00 | per roll | p. 48 | ||
| B899-2-00 | Rail Connector | $41.66 | each | p. 48 | ||
| 52002-25 | Slim Line Ball Bearing Carrier | 59 black, 65 brown, 90 grey + 10% | $0.80 | each | box of 1000; broken box $0.98 each | p. 48 |
| B11670-120-XX | Extended Wall | $226.88 | each | p. 48 | ||
| B8809-23-00 | Overlap R | $15.43 | each | box of 25; broken box $18.55 each | p. 48 | |
| B8809-24-00 | Underlap L Plastic Snap Master | 59 black + 10% | $15.43 | each | box of 25; broken box $18.55 each | p. 48 |
| B11672-190-XX | Double Wall Bracket | $257.32 | each | p. 48 | ||
| 52502-25 | Overlap R | $8.81 | each | box of 100; broken box $10.56 each | p. 48 | |
| 52504-25 | Underlap L Standard Multi-Functional Master Use stiffener w/ exposed baton | 59 black + 10% | $8.81 | each | box of 100; broken box $10.56 each | p. 48 |
| B11873-50-XX | Ceiling Bracket | $155.35 | each | p. 48 | ||
| 52502-25A | Overlap R | $10.67 | each | box of 100; broken box $12.79 each | p. 48 | |
| 52504-25A | Underlap L Standard Multi-Functional Master w/ snaps | 59A black + 10% | $10.67 | each | box of 100; broken box $12.79 each | p. 48 |
| B11873-15-XX | Ceiling Bracket 5/8" Projection | $82.54 | each | p. 48 | ||
| 52411-25A | Butt R | $37.73 | each | box of 50; broken box $45.29 each | p. 48 | |
| 52412-25A | Butt L Wheeled Butt Master | 59A black, 65A brown, 90A grey | $37.73 | each | box of 50; broken box $45.29 each | p. 48 |
| B122028-XX | Inside Mount Bracket | $135.91 | each | p. 48 | ||
| B122928-XX | Swivel Elbow | $258.42 | each | p. 48 | ||
| 53408-22 | Flush Ceiling Bracket Cannot use finials | 22, 25, 29, 59, 70 | $30.67 | each | p. 48 | |
| V799-2-00 | End Stop | $1.06 | each | box of 100; broken box $1.28 each | p. 48 |
Hardware only. Professional installation is quoted at the measure. Prices are 2026 retail, before tax, and may change.
What finishes does the Forest Dresden traversing rod come in?
Finish codes as Forest prints them; the code replaces XX in the part number.
- 22Polished Chrome
- 24Satin Brass
- 29Satin Nickel
- 48Matte White
- 59Black
- 70Bronze Matte
- 222Beech (poles only)
- 223Oak (poles only)
- 224Walnut (poles only)
Forest Dresden traversing rod finials and prices
H is the height and P the projection from the end of the rod, where Forest publishes them. Pictures from Forest's library show one finish of each finial.
End Cap FinialB124028-XX
$67.98 each
Pescara FinialB690-XX
$383.54 each
Alassio FinialB3362-XX
$388.37 each
Alea FinialB124128-XX
$96.44 each
Napoli FinialB610-XX
$482.35 each
Iscia FinialB3521-28-XX
$333.31 each
Flush Ceiling Bracket Cannot use Finial53408-22
$30.67 each
Hardware only. Professional installation is quoted at the measure. Prices are 2026 retail, before tax, and may change.
Where the Forest Dresden traversing rod fits
Pinch pleat drapery on a Dresden rod is the classic look for formal living and dining rooms, and it suits a Palm Beach or Coral Gables interior that already has brass or bronze on the doors. Forest decorative rods carried the hand-drawn drapery at our Fasano Fifth Avenue project. The motorized version is Dresden Motor 2.0.
Forest Dresden traversing rod: frequently asked
How much does a Forest Dresden traversing rod cost?
A 6 ft Forest Dresden traversing rod (single) costs $1,368.71; a 12 ft one costs $2,328.53. A 6 ft Forest Dresden traversing rod (double) costs $2,736.84; a 12 ft one costs $4,654.86. Prices are Forest's 2026 retail for the hardware only; installation is quoted at the measure.
What is the weight limit of the Forest Dresden traversing rod?
Forest rates it at 4 lb per foot, depending on the application.
What finishes does the Forest Dresden traversing rod come in?
22 Polished Chrome, 24 Satin Brass, 29 Satin Nickel, 48 Matte White, 59 Black, 70 Bronze Matte, 222 Beech, 223 Oak, 224 Walnut. XX in a part number stands for the finish code.
Can the Forest Dresden rod curve?
Yes. Dresden Traversing curves and reverse curves to an 8 inch radius or a continuous curve, bent by Forest from an exact template.
How many brackets does a Dresden rod need?
Forest specifies two brackets up to 60 inches, three to 120 inches, four to 180 inches and five to 240 inches.
